Газовый клапан Honeywell VR4305

Газовый клапан Honeywell VR4305
Выберите модификацию:
Выберите количество:
  • Combination gas control for use with hot surface/direct spark systems in 120 Vac, gas-fired appliances, with capacities from 30 to 415 cfh

Product Features:
  • Controls include manual valve, two automatic operators and pressure regulator
  • Compact size
  • Provides two automatic valves
  • Solenoid operated first automatic valve opens on thermostat call for heat; closes when call for heat ends
  • Diaphragm-operated second automatic valve opens under control of regulator; closes if gas or power supply is interrupted
  • Meets codes requiring dual safety shut-off
  • Natural to LP and LP to Natural conversion kits available for standard and slow opening gas valves
  • Adjustable servo regulator effectively maintains almost constant gas output pressure under wide fluctuations in gas supply pressure
  • ON/OFF lighting sequence

Product Specifications:
  • Description: 120 Vac Dual Direct Ignition Gas Valve with 3/4 in. x 3/4 in. inlet/outlet, standard opening and 3.5 in. wc pressure regulator setting
  • Type: Single Stage
  • Ignition Type: Direct Ignition
  • Type of Gas: Natural
  • Inlet/Outlet Size (in.): 3/4 in. x 3/4 in.
  • Body Pattern: Straight-through
  • Opening Characteristics (standard, step): Standard
  • Capacity @ 1 in. p.d.: 300,000 BTU/hr; 30,000 BTU/hr minimum
  • Pressure Ratings (psi): 1/2 psi
  • Pressure Ratings (kPa): 3.5 kPa
  • Pressure Regulator Setting (psi): 3.5 in. wc
  • Pressure Regulator Setting (kPa): 0.87 kPa
  • Pressure Tapping: 1/8 in. NPT with plug
  • Electrical Connections: 1/4 in. male quick-connects; 24 in. (610 mm) leadwires.
  • Electrical Ratings: 120 Vac
  • Frequency: 60 Hz
  • Anticipator Setting: 0.13 A
  • Temperature Range (F): -40 F to +175 F
  • Temperature Range (C): -40 C to +79 C
  • Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically
  • Includes: Two 3/4 x 1/2 in. reducer bushings, natural to LP Conversion Kit, one 1/2" x 3/8" reducer bushing
  • Approvals, American Gas Association IAS: AGA Design Certified: File No. L2025007
  • Approvals, Canadian Gas Association: CSA Design Certified: File No. L2025007
  • Approvals, Underwriters Laboratories Inc: UL Component Recognized

Доступные для заказа модификации:

МодификацияАртикул
VR4305M 4532 (U)VR4305M4532/U


Вы можете купить газовый клапан Honeywell VR4305, сделав заказ через корзину интернет-магазина.

Если вам нужна помощь в выборе Газовых клапанов серии VR46.., VR86.. или другого оборудования Honeywell, обратитесь к нашему техническому специалисту. Это можно сделать:

  • по электронной почте zakaz@honeyvell.ru;
  • по телефону +7 (495) 542-34-33.

Доставку оборудования Honeywell мы производим во все регионы РФ. Самостоятельно забрать выбранный вами товар можно на нашем складе в г. Мытищи Московской области.
